Aaton Cantar X3

Description

Features:

• 24 tracks digital on-site audio recorder with embedded mixer plate and intuitive interface.
• Analog and Digital Inputs
• 12 analog inputs on XLRs
• 8 low noise mic preamps with very high quality transformer, 48V Phantom, limiters and filters
• 4 analog line inputs
• Multiple AES digital inputs includes 2 AES42 pairs (mode 2), 8 AES/EBU and a Dante Audinate network access
• Mixer and Outputs
• Ten tracks mixer plate with magnetic linear assignable faders
• All inputs can be routed to any of the 24 tracks
• All tracks and inputs can be routed to 8 analog auxiliary outputs and /or digital outputs
• Mixdown can be assigned to any of the tracks
• Recording Media
• Records and playback to and from internal 256 Gg SSD drive (expandable SSD size)
• Simultaneous recording to internal SSD drive, two SD cards and USB external drive
• Metering and Controls
• Ultra bright large swivelling display panel, visibility optimised for shoulder work or cart
• Two large rotary control selectors for easy record and operations in any situations
• Linear control faders addressable to any inputs and output
• New improved interface menu accessible through buttons, jog wheel – All inputs and outputs monitoring and routing available through comprehensive and intuitive menus
• USB keyboard input for easy metadata editing and routing control
• Wifi and Bluetooth communication
• Power
• Two identical on board quick release smart batteries insure seamless switchover during recording
• One XLR4 DC 10-30 Volts input for extra power inputs when working on cart
• More Specifications
• Generates reports (PDF and database), patented auto slate detection
• Housing made of machined avionic aluminium
• Ultra-resistant coatings
• Waterproof and dustproof
• Modular conception for easy service and upgradibility of the Cantar X3

Dimensions: 240 X 320 X 90 mm
